Aneng DM850 Digital Multimeter

Product detailed description

Aneng DM850 is a pocket digital multimeter with manual range selection and a 3½-digit LCD display. It allows you to measure DC and AC voltage, DC current and resistance, perform continuity tests, test diodes, determine transistor gain (hFE), and check the approximate status of alkaline batteries. Thanks to its compact dimensions and rubber protective boot, it is ideal as a first multimeter for beginner hobbyists or as a backup device for your bag.

Specifications:

• Display: 3½-digit LCD, max. reading 1999
• Range selection: manual, via rotary switch
• Measurement ranges:
  • DC Voltage: 200 mV / 2 V / 20 V / 200 V / 600 V
  • AC Voltage: 200 V / 600 V
  • DC Current: 2 mA / 20 mA / 200 mA / 10 A
  • Resistance: 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ / 2 MΩ
• Other functions:
  • Diode Test: yes
  • Continuity: yes, with acoustic signalling
  • Transistor Test (hFE): NPN and PNP, separate E-B-C-E socket
  • Battery Test: approximate measurement of 1.5 V cell status (AA, AAA, C, D)
  • HOLD: holds the measured value on the display
• Measuring inputs:
  • 10A: current measurement up to 10 A, unfused, max. 10 s
  • COM: common input
  • mA / VΩ: voltage, resistance, current up to 200 mA (fused 200 mA / 250 V)
• Measurement Category: CAT II 600 V
• Power Supply: 1× 9 V battery type 6F22 (not included)
• Material: ABS with rubber protective frame
• Dimensions: approx. 139 × 74.5 × 33.6 mm

Safety and warnings:

• The 10A input is not fuse-protected — do not measure with it for more than 10 seconds at a time and never connect probes to it when measuring voltage.
• The device is rated CAT II 600 V. It is intended for measurements on appliances and in circuits downstream of the electricity meter, not for fixed installations or distribution boards (CAT III / CAT IV).
• Always disconnect the test probes from the circuit before turning the rotary switch to a different mode.
• The multimeter does not measure alternating current, capacitance, frequency, or temperature.

Package contents:

• 1× Aneng DM850 Multimeter
• 1× pair of test leads with probes (red and black)

Note:

• 9 V battery is not included.
• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
