Rain Sensor YL-83

Product detailed description

The YL-83 rain sensor is used to detect rain, sleet, or generally the presence of water on the detection surface. It consists of a sensing board with exposed conductive tracks and an evaluation module with an LM393 comparator. Once water droplets bridge the tracks on the sensing board, its resistance changes, and the module provides both an analogue output (proportional to the amount of water) and a digital output with adjustable sensitivity via a trimmer. The sensor is ideal for weather stations, automatic closing of windows or roof lights, and other DIY projects with Arduino or ESP32.

Specifications:

• Model: YL-83 (sensing board + LM393 comparator module)
• Power Supply: 3.3–5 V DC
• Current Consumption: approx. 8 mA (with LEDs active)
• Outputs:
  • AO: analogue output – voltage decreases with the amount of water on the board
  • DO: digital output – LOW when the set threshold is exceeded (TTL)
• Pins: 4 (VCC, GND, DO, AO)
• Sensitivity Adjustment: potentiometer (trimmer) on the module
• Indication: 2× LED (power, digital output trigger)
• Sensing Board Dimensions: approx. 54 × 40 mm
• Module Dimensions: 40 x 50 mm

Package contents:

• 1× YL-83 rain sensor sensing board
• 1× evaluation module with LM393 comparator
• 1× connecting cable (2 conductors)

Note:

• For a longer lifespan, we recommend powering the sensing board only at the moment of measurement (e.g., from a GPIO pin) and placing it at an angle of approx. 20° to allow water to drain.
• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
