    Digital isolator ADUM1201 2 channels - UART, IO

    Code: LA161062
    The average product rating is 5,0 out of 5 stars. 1 rating Rating details
    ADUM1201
    €3,16 €2,61 excl. VAT
    In stock (92 pcs)
    Delivery to:
    20/05/2026

    Digital isolator for galvanic isolation of UART data buses etc.

    Detailed information

    Free Shipping
    Free Shipping
    From 100 EUR
    30 Days to Return
    30 Days to Return
    For Registered
    30 Days to Return
    30 Days to Return
    For Registered Customers
    Free Shipping
    Free Shipping
    For orders from 100 EUR
    It Doesn't End With Shipping
    Customer Care
    We handle complaints within 5 days
    Quick dispatch
    Quick dispatch
    Within 24 hours

    Product detailed description

    Digital isolator ADUM1201 2 channels - UART, IO

    Digital isolator for galvanic isolation of UART data buses etc. Ideal wherever galvanic isolation of communication buses or I/O ports is required. Can also be used as a 3.3V/5V logic level converter.

    Specifications:

    • Supply voltage: 2.7-5.5V
    • Current consumption: approx. 8mA max.
    • Transmission speed: max. 1Mbps
    • Number of channels: 2
    • Dimensions: 21x10.1mm

    Included in delivery:

    • 1pc Digital isolator ADUM1201 2 channels - UART, IO

    Note:

    • This product is not a standalone functional unit and may require professional installation.
    • Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.

    Additional parameters

    Category: Converters & Programmers
    Warranty: 2 years
    Weight: 0.001 kg
    8 kanály Obousměrný převodník logických úrovní 5V a 3.3V
    8 channels Bidirectional converter of logic levels 5V and 3.3V
    The average product rating is 4,3 out of 5 stars.
    In stock (65 pcs)
    €1,16 excl. VAT
    €1,40

    Converter from logic 3.3V to 5V or vice versa with eight channels, which is useful for connecting boards like ESP32 to peripherals operating on 5V logic.

    LA161007
    cjmcu 220
    USB to SPI converter, FT220X
    In stock (7 pcs)
    €8,08 excl. VAT
    €9,78

    USB to SPI converter, FT220X

    LA161059
    Převodník signálu z 4-20mA na V
    Signal converter from 4-20mA to V
    The average product rating is 5,0 out of 5 stars.
    Currently not available
    €1,63 excl. VAT
    €1,97

    Signal converter from 4-20mA to 0-10V.

    LA161027
    Show all alternative products

    Product rating

    The average product rating is 5,0 out of 5 stars. 1 rating
    5
    1x
    4
    0x
    3
    0x
    2
    0x
    1
    0x

    Leave a rating

    Do not fill out this field:

    How would you rate this product? Choose 1 to 5 stars, where 1 is the worst and 5 is the best rating.

    List of ratings

    5
    JV Avatar of author The product rating is 5 out of 5 stars. | 27/12/2021
    Funguje spolehlivě na rychlosti 115200Bd. Jedna strana běží na 5V logice/arduino Nano, druhá běží na 3.3V/ESP32.

    Discussion

    Do not fill out this field:

    List of discussions

    PK Avatar of author Velikost pcb 18/07/2025 07:35
    Dobrý den, nikde není napsáno jaké rozměry má osazená deska, potřeboval bych ji osadit do svého projektu, ale nevím kolik místa jí mám nechat na umístnění.
    MF Avatar of author Velikost pcb 18/07/2025 08:24
    Dobrý den, rozměry jsou 21x10,1mm. Doplnili jsme i do popisu zboží.
    M Avatar of author I2C 13/04/2023 12:21
    Dobrý den, chtěl bych se zeptat zda-li je součástka kompatibilní s I2c komunikací? Děkuji předem.
    MF Avatar of author I2C 13/04/2023 12:47
    Dobrý den, tento modul je vhodný pro UART, SPI a podobné sběrnice. Bohužel I2C je specifická v tom, že probíhá datová komunikace obousměrně a to tento izolátor neumí.
    MP Avatar of author Problém s rychlostí 23/03/2022 12:05
    Prřenosová rychlost nemusí být 25Mbps, záleží na provedéní čipu. ten co je na fotce má označení ARZ, to znamená že Max rychlost je 1Mbps. Pozor objevil jsem čipy s označením BRZ = 10Mbps ale byli to ARZ, pouze 1Mbps. Čipy s rychlostí 25Mbps mají označení CRZ
    MF Avatar of author Problém s rychlostí 23/03/2022 12:08
    Dobrý den, děkujeme za upzornění, údaj jsme v popisu opravili na 1Mbps.
