KDA5 Bistable Flip-Flop push button module

Product detailed description

Module for switching the power on and off with one button. You can set the button press time required to flip the output and the default state of the output when the power is turned on.

The setting is done by jumpers on the bottom of the module:

If all jumpers are unconnected, the module is in the basic setting: the button ON time is 0s and the output state after power on is in the OFF state.

Connectors 1 - 3 are used to set the button switching time:

1. by interconnection the required button press time for output activation will be 1s
2. by interconnection the required button press time to activate the output will be 2s
3. by interconnecting, the required button press time for output activation will be 4s

Connectors can be combined with each other to achieve a push button switching time of 1 - 7s.

Jumper 4 sets the output status after power supply connection:

• Jumper disconnected: output open
• Jumper connected: output closed

Specifications:

• Power supply: 3 - 18V
• Current draw at empty: 2μA
• Current draw with output switched on: 2mA
• Output switching current: 1.5A max
• Output type: Open collector (switches to GND)

Included in delivery:

• 1pc KDA5 Bistable Flip-Flop Button Module

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
