LaskaKit LM66200 Power Swapper power switch

Product detailed description

Two possible voltage sources (maybe two batteries) that you can connect to your device? How to connect it? Maybe through a diode to your device, but there will be a voltage drop across the diode and it will also cause power loss.

That's why we designed the LM66200 Power Swapper - a module with an LM66200 integrated circuit. This integrated circuit contains a circuit called an ideal diode. The resistance of this diode is 40 mR, the maximum current flowing is 2.5A and the operating voltage from 1.6V to 5.5V.

With this module, you simply connect two voltage sources to your device so you don't have to worry about any buffer currents between the input sources or voltage drop across the diodes.

Specifications:

• Load voltage: 1.6-5.5V
• Control voltage: 3.3-5V
• Output current: max 2.5A
• Dimensions: 14x10mm

Included in delivery:

• 1pc LaskaKit LM66200 Power Swapper power switch

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
