LILYGO® T-Embed CC1101 ESP32-S3 1.9 ST7789, Clear Case

Product detailed description

The LILYGO® T-Embed CC1101 is a versatile development board with an ESP32-S3 microcontroller, complemented by a 1.9" colour TFT ST7789 display, a CC1101 wireless module, and housed in an attractive clear plastic case. It offers rich connectivity thanks to Wi-Fi, Bluetooth and low-frequency RF communication (315/433/868/915 MHz depending on the CC1101 variant), making it an excellent foundation for IoT devices, remote controls, RF scanners or wireless buttons.

Key features:

• Powerful ESP32-S3 chip with Wi-Fi and Bluetooth 5.0 LE support
• Wireless RF module CC1101
• 1.9" TFT colour display ST7789, 320×170 px
• Built-in MSM261D3526H microphone and speaker
• USB-C connector for power and programming
• Internal RGB LED
• Open clear case – visible electronics and access to connectors
• Supports Arduino and ESP-IDF

Specifications:

• MCU: ESP32-S3 (Xtensa® LX7 dual-core)
• Memory: 16 MB Flash, 8 MB PSRAM
• Display: 1.9" TFT ST7789 (320×170)
• RF module: CC1101 868MHz
• Audio input/output: MEMS microphone + speaker
• Buttons: 1 × rotary encoder
• USB interface: USB-C
• Power: 5V via USB-C
• Dimensions (incl. case): approx. 96 × 39 × 31 mm

Package contents:

• 1× LILYGO® T-Embed ESP32-S3 with display in black case

Comment:

• This product is not a self-contained functional unit and may require professional assembly or programming.
• Product photos are for illustrative purposes only and may differ slightly from the actual appearance.
• For development, you can use Arduino IDE, PlatformIO or ESP-IDF.
