Melexis MLX90641 Thermal Camera 16×12px 55°x35°

Product detailed description

The Melexis MLX90641 is a compact infrared thermal camera module with a resolution of 16×12 pixels, enabling non-contact temperature measurement. Thanks to its wide field of view of 55° × 35°, it is suitable for monitoring larger areas in both industrial and hobby applications. The module communicates via the I²C bus, ensuring easy integration with Arduino, ESP32, and other microcontrollers.

Specifications:

• Model: Melexis MLX90641
• Resolution: 16 × 12 pixels (192 pixels)
• Temperature measurement range: -40 °C to +300 °C
• Refresh rate: up to 64 Hz
• Field of view (FOV): 55° × 35°
• Interface: I²C (up to 1 MHz)
• Power supply: 3.3 V (typical)
• Module dimensions: approx. 11.5 × 11.5 mm

Package contents:

• 1x Thermal Camera Melexis MLX90641 (FOV 55°×35°)

Note:

• This module requires a microcontroller for data processing (not included).
• Product photos correspond to the real product, but in exceptional cases may differ, e.g. in the PCB colour.
