DC Motor RS-775VC-8016 18V 11 teeth

Product detailed description

The RS-775VC-8016 18V DC motor (11 teeth) is a powerful brushed DC motor designed for demanding applications requiring high torque and reliable operation. Thanks to its robust metal construction and precise rotor mounting, it is suitable for use in power tools, modelling, fan drives, pumps or small mechanisms. This type of motor is popular for its power, size and price ratio.

Specifications:

• Dimensions:
  • Shaft length: 12.5 mm (axis length above step level)
  • Shaft diameter: 5 mm
  • Motor diameter: 46 mm
  • Motor length: 66.5 mm
  • Spacing of mounting holes: 29mm
  • Diameter of mounting holes: 2x M4
• Gear wheel with a diameter of 10.8 mm and 11 teeth.
• Weight: 390g
• Rotational speed, voltage and current

  • 5900 rpm at 6.0V, 1.25A
  • 7400 rpm at 7.5V, 1.40A
  • 9000 rpm at 9.0V, 1.50A
  • 12100 rpm at 12V, 1.60A
  • 15400 rpm at 15V, 1.80A
  • 18500 rpm at 18V, 2.0A
  • 21700 rpm at 21V, 2.10A
• Block current: 100A
• Power: approx. 9-300W

Scope of Delivery:

• 1pc Motor JGB37-550 12V with gearbox.

Note:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
• Be careful, the engine has a scratched surface.
