Espressif ESP32-WROOM-32 2.4GHz WiFi+Bluetooth Module
Code: LA100043
Related products
Product detailed description
Standalone ESP-32 module, which is equipped with a highly integrated and powerful 32-bit microprocessor with many GPIO pins, which can perform activities according to the programmed code.
The board is compatible with every standard development environment.
Specifications
| Key features Co-extrusion technology: two colours in one strand Dynamic colour transitions depending on the viewing angle Colour-change effect Smooth, silky printed surface High aesthetics and unique character of models Compatibility with most FDM/FFF 3D printers Easy printing |
Dual-core 240 MHz Tensilica LX6 microcontroller with 600 DMIPS Integrated 520 KB SRAM Integrated 802.11 b/g/n HT40 Wi-Fi transceiver, baseband, stack and LWIP Integrated dual-mode Bluetooth chip (classic and BLE) 4 MB flash memory Input voltage from 3.0V to 3.6V Operating temperature -40°C to +125°C Antenna on PCB (PCB) |
| Sensors |
Ultra-low noise analogue amplifier Hall probe 10x capacitive touch interfaces 32 kHz crystal oscillator |
| 34x GPIOs |
3 x UART 3 x SPI 2 x I2S 12 x ADC inputs 2 x DAC 2 x I2C PWM on each pin OpenOCD debugging interface with 32 kB TRAX buffer SDIO master/slave 50 MHz Supports external SPI flash memory up to 16 MB SD card support |
|
Protection |
WEP, WPA/WPA2 PSK/Enterprise Hardware accelerated encryption: AES/SHA2/Elliptical Curve Cryptography/RSA-4096 |
| Performance |
Supports sniffer, Station, SoftAP and Wi-Fi direct mode Max data rate of 150 Mbps@11n HT40, 72 Mbps@11n HT20, 54 Mbps@11g, and 11 Mbps@11b Maximum transmitter power 19.5 dBm@11b, 16.5 dBm@11g, 15.5 dBm@11n Minimum receiver sensitivity: -98 dBm 135 Mbps UDP throughput Power consumption of 5 µA in deep sleep mode |
Scope of Delivery:
- 1x Espressif ESP32-WROOM-32 2.4GHz WiFi+Bluetooth Module
Note:
- This product is not a standalone functional unit and may require professional installation.
- Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
Additional parameters
| Category: | ESP Development Boards |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.002 kg |
| Type: | ESP |
| Logical levels: | 3.3V |
| Frequency: | 40MHz |
| Flash memory: | 16MB |
| SRAM memory: | 520kB |
| EEPROM memory: | Ne |
| Connector with battery charger: | No |
| Microcontroller: | ESP32 |
| Converter: | No |
| Bluetooth: | Yes |
| WiFi: | Yes |
| Ethernet: | Ne |
