Krokový motor NEMA 8 20HS34 0,02Nm

Product detailed description

The NEMA 11 11HS2810 stepper motor is a compact, accurate and reliable motor suitable for small CNC machines, 3D printers, automation systems and other applications requiring precise motion control. Its small size and high precision make it ideal for tasks with limited space.

Stepper motor Nema11, bipolar two-phase. Stepper motor for smaller CNC machines, offering 200 steps per revolution accuracy. The motor outputs are terminated with a JST-XH-4 connector.

Specifications:

• Model: 11HS2810 (marked 28HS28)
• Motor type: bipolar stepper motor
• Step angle: 1.8° (200 steps/turn)
• Rated current: 1.0 A/phase
• Winding resistance: 2.7 Ω
• Winding inductance: 2.0 mH
• Torque: 80mN.m
• Flange dimensions: NEMA 11 (28 × 28 mm)
• Motor length: 28 mm
• Shaft diameter: 5 mm
• Shaft type: D
• Shaft length: 20 mm
• Connection: 4 wires (bipolar) 34cm
• Wire connections: red = A+, green = A-, yellow = B+, blue = B-
• Weight: Approximately 100 g

Included in delivery:

• 1pc Stepper Motor NEMA 11 11HS2810 0.08Nm

Note:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
