LaskaKit Live-7.5 E-paper kit with WiFi for ”Living Image” V2.1

Product detailed description

Build your own "Živý obraz"! Get a smart e-Paper display that communicates with the Živý obraz server via Wi-Fi to get almost any information you want. The kit also includes a powerful battery that can last from weeks to years of use, depending on the refresh frequency.

The construction is simple and can be recommended even for beginners. No soldering required. Simply connect the e-Paper via the adapter and shielded cable to the development board, move everything into the frame, which you can either 3D print yourself or order from us, screw it together, connect the battery, flash the firmware, connect to Wi-Fi, and you're up and running. You can then send the content you want to display to the ePaper via the service.

What's new:

V2.1:

• Larger battery, 6000mAh
• Box is 1mm thicker

V2.0:

• Added battery power switch
• STH40 temperature and humidity sensor

What is Living Picture:

A web-based service that greatly simplifies the process of getting information onto the e-Paper frame. You can simply upload your own image to the station, have the image retrieved from any URL available on the Internet, create a gallery of images to display them in sequence, use the existing smart gallery to get a calendar including an optional weather forecast, or create a Screen. The Screen is a custom overview page that you can design on the Living Picture server completely to your liking. You can place values on it, which you can also send to the server from your own home automation or get them from your current account in the TMEP service. There are really many options. More information can be found on the service website https://zivyobraz.eu/.

Upload FW conveniently in your browser:

• Our own FW
• FW from zivyobraz.eu (Select the ESPInk 2.x and 3.5 board and the selected display)

The product is available in multiple variants:

• 1️⃣ Display – Choose Between Black-and-White, Red-Black-and-White, and Four-Color Versions
• 2️⃣ Case – choose the colour of the 3D printed case, or the Print it myself option
• 3️⃣ Assembly – decide whether you want the product delivered as a kit (DIY) or assembled and programmed

Parts list:

• 1pc LaskaKit ESPink ESP32 e-Paper PCB antenna
• 1pc ePaper display to choose from:
  • Black & White: Good Display GDEY075T7 7.5" 800x480 (fast update, 3.5s)
  • Red-Black-White: Good Display GDEY075Z08 7.5" 800x480 (slow refresh, 26s)
  • Four-colour: Good Display GDEM075F52 7.5" 800x480 (slow update, 22s)
• 1pc LaskaKit e-Paper FFC FPC 24pin adapter
• 1pc FFC FPC unshielded flexible cable AWM 20624 80C 60V 0.5mm 24pin, 20cm
• 1pc LaskaKit LiPol Battery 6000mAh
• 1pc LaskaKit SHT40 Air temperature and humidity sensor
• 1pc μQuick JST-SH 4-pin cable - 20cm
• 1pc LaskaKit JST-PH-2 connector with cable 5cm
• 1 pc LaskaKit Battery Power Switch
• 10pcs Screw for thermoplastics with lens head and cross groove 2,2x8 BN 82428 steel
• 4 pcs Screw for thermoplastics with lens head and cross slot 2.2x5BN 82428 steel

Image	Product/Variant	e-Paper Panel Type	Diagonal	Resolution	Refresh	Capacity + Battery Life
	LaskaKit IoT E-ink-1.54_4C Display: Four-Color	GDEM0154F51H	1.54"	200 × 200	20s	650 mAh approx. 2 to 4 months
	LaskaKit Live-2.13 Display: Black-and-White	GDEY0213B74	2.13"	250 x 122	3s	1000 mAh approx. 2 to 4 months
	LaskaKit Live-2.13 Display: Four-Color	GDEY0213F52	2.13"	250 x 122	25s	1000 mAh approx. 1 to 3 months
	LaskaKit Live-2.9 Display: Black-and-White	GDEY029T71H	2.9"	384 x 168	3s	1800 mAh approx. 3 to 6 months
	LaskaKit Live-2.9 Display: Four-Color	GDEY029F51H	2.9"	384 x 168	25s	1800 mAh approx. 2 to 4 months
	LaskaKit Live-4.2 Display: Black-and-White	GDEY042T81	4.2"	400 × 300	3s	1200 mAh approx. 2 to 4 months
	LaskaKit Live-4.2 Display: Four-Color	GDEM042F52	4.2"	400 × 300	20s	1200 mAh approx. 1 to 3 months
	LaskaKit Live-4.26 Display: Black-and-White	GDEQ0426T82	4.26"	800 × 480	3.5s	2000 mAh approx. 2 to 4 months
	LaskaKit Live-5.83 Display: Black-and-White	GDEQ0583T31	5.83"	648 × 480	3s	4000 mAh approx. 3 to 8 months
	LaskaKit Live-5.83 Display: Four-Color	GDEY0583F41	5.83"	648 × 480	20s	4000 mAh approx. 2 to 6 months
	LaskaKit Live-7.4 Display: Black-and-White	E2741CS0B2	7.4"	800 × 480	4s	6000 mAh approx. 4 to 12 months
	LaskaKit Live-7.4 Display: Red-Black-White	E2741FS081	7.4"	800 × 480	32s	6000 mAh approx. 3 to 6 months
	LaskaKit Live-7.5 Display: Black-and-White	GDEY075T7	7.5"	800 × 480	3.5s	6000 mAh approx. 4 to 12 months
	LaskaKit Live-7.5 Display: Four-Color	GDEM075F52	7.5"	800 × 480	22s	6000 mAh approx. 3 to 6 months
	LaskaKit Live-7.x-Pro Display: Six-color	GDEP073E01	7.3"	800 × 480	14~19s	6000 mAh approx. 3 to 7 weeks
	LaskaKit Live-7.x-Pro Display: Black-and-White	GDEY075T7	7.5"	800 × 480	3.5s	6000 mAh approx. 4 to 12 months
	LaskaKit Live-7.x-Pro Display: Four-Color	GDEM075F52	7.5"	800 × 480	22s	6000 mAh approx. 3 to 6 months
	LaskaKit Live-10.2 Display: Black-and-White	GDEM102T91	10.2"	960 × 640	4s	5000 mAh approx. 3 to 6 months
	LaskaKit Live-10.2 Display: Four-Color	GDEM102F91	10.2"	960 × 640	20s	5000 mAh approx. 2 to 4 months
	LaskaKit Live-11.6 Display: Black-and-White	GDEY116T91	11.6"	960 × 640	5s	8000 mAh approx. 2 to 5 months
	LaskaKit Live-11.6 Display: Red-Black-White	GDEY116Z91	11.6"	960 × 640	28s	8000 mAh approx. 2 to 4 months
	LaskaKit Live-11.6 Display: Four-Color	GDEY116F51	11.6"	960 × 640	20s	8000 mAh approx. 1 to 3 months
	LaskaKit Live-12.48 Display: Four-Color	GDEY1248F51	12.48"	1304 × 984	26s	10000 mAh approx. 3 to 12 months
	LaskaKit Live-13.3 Display: Black-and-White, 16 Shades	GDEP133UT3	13.3"	1600 × 1200	1s	12000 mAh approx. 4 to 8 months

Package Contents:

• 1x LaskaKit Live-7.5 E-paper kit with WiFi for "Live Picture" V2.1

Note:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
