13.3" 2K 2560x1440 TFT display, HDMI, touch

Product detailed description

The capacitive touch 13.3" TFT display with 2K resolution (2560 × 1440 pixels) and tempered glass is suitable as a portable second monitor for a laptop, a screen for Raspberry Pi or mini PC, a control panel for industrial and home applications, or the base for your own device with a large touch surface. The image is supplied via one of two mini HDMI inputs; touch functionality works via USB as a standard HID device without the need for driver installation in Windows, Linux (including Raspberry Pi OS and Ubuntu), and macOS, and supports multi-touch. Additionally, the driver board transfers audio from HDMI to a 3.5mm headphone jack or to a speaker output.

Specifications:

• Display: 13.3" TFT, viewing angle up to 160°
• Resolution: 2560 × 1440 pixels (2K, 16:9 aspect ratio)
• Touch: capacitive, multi-touch, 2H hardness tempered glass
• Panel interface: eDP, 40pin (driver board included)
• Driver board connectors:
  • Video: 2× mini HDMI (video and audio input)
  • USB: micro USB – touch and 5 V power supply
  • Power: DC jack 12 V
  • Audio: 3.5mm headphone jack, speaker connector
  • Keypad: connector for control buttons (OSD menu)
• Power supply: 12 V DC via the included adapter, or 5 V via micro USB
• Compatibility: Raspberry Pi 5 / 4 / 3, mini PCs, laptops and PCs with HDMI output; Windows, Linux, macOS
• Dimensions:
  • Display: 304 × 178 × 11 mm
• Weight: 430 g

Good to know:

• The display is supplied as a panel with a driver board attached to the rear; it does not have a plastic cover. For permanent use, we recommend using your own frame or enclosure (e.g. via 3D printing).
• HDMI cable is not included. The display has mini HDMI inputs – for Raspberry Pi 5 / 4, you will need a micro HDMI to mini HDMI cable; for a standard PC or laptop, an HDMI to mini HDMI cable.
• The touch interface must be connected to the computer via a micro USB cable; without it, the display functions only as a monitor.
• According to customer experience, USB power alone is sufficient for the display when used with Raspberry Pi 5, provided the Raspberry Pi is powered by the original adapter. If the USB port provides insufficient power, use the included 12V adapter.
• The included power supply has a US plug; a converter for European sockets is included in the package.

Package contents:

• 1× 13.3" 2K Touch TFT Display with Driver Board
• 1× USB-A to micro USB cable
• 1× display stand
• 1× 12 V power adapter (US plug + adapter)

Note:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
