LaskaKit ESPwled

Product detailed description

LaskaKit ESPwled is a development board with an ESP32-C3 chip designed for the open-source WLED project, allowing you to control addressable LED strips via Wi-Fi without the need for programming. You can easily flash the WLED firmware to the board using the project's web browser, and then control the strips from a browser on your phone, tablet, or computer. The board supports 5V, 12V and 24V LED strips, compatible with single-wire (WS2812B, SK6812…) and dual-wire strips with a clock signal (APA102), and also features μSup connectors for I2C and SPI, allowing you to connect sensors and other peripherals.

How to upload WLED:

• Connect the board to your computer via a USB-C cable.
• Switch the ESP32-C3 to flashing mode: press and hold the FLASH button, press and release the RESET button, and then release the FLASH button.
• In the WLED project browser, select the connected LaskaKit ESPwled board and upload the program.
• Connect (e.g. via smartphone) to the Wi-Fi AP created by ESPwled and enter the name and password of your Wi-Fi network.
• ESPwled will then connect to your Wi-Fi, allowing you to control the connected LED strips via a browser on your phone, computer, or tablet.
• Important: The data pin for the LED strip is GPIO 5, not GPIO 2 as set in the WLED default settings – therefore, the pin must be changed in the WLED settings (via the web browser). If the LED strip also has a CLK signal, it is connected to GPIO 4.

Specifications:

• Sales Version: V1.0
• ESP Module: ESP32-C3 (Wi-Fi, Bluetooth LE)
• Flash: 4 MB
• Power Supply:
  • USB-C: 5 V (for 5V LED strips only)
  • From LED Strip: 5–24 V for 5V, 12V and 24V LED strips
• Variants:
  • PCB: integrated on-board antenna
  • IPEX: IPEX3 (MHF3) connector for external antenna
• Pinout (GPIO):
  • LED DATA: GPIO 5
  • LED CLOCK: GPIO 4 (only for dual-wire LED strips, e.g. APA102)
  • Integrated addressable LED: GPIO 9
  • I2C SDA: GPIO 10
  • I2C SCL: GPIO 8
• Interface:
  • I2C: μSup connector (Qwiic, STEMMA QT), SDA GPIO 10, SCL GPIO 8 – pins must be defined before initializing the I2C module: Wire.begin(10, 8); // (SDA, SCL)
  • SPI: μSup connector for connecting additional SPI peripherals
  • USB-C: firmware flashing and power supply
• Integrated addressable LED: on GPIO 9, sample code for its control can be found on our GitHub
• LED strip connector: not populated, 2.54 mm pitch (can be populated with a JST-XH connector, screw terminal block or pin header)
• Suitable I2C sensors with μSup, e.g.:
  • SHT40 (temperature, humidity)
  • BME280 (pressure, temperature, humidity)
  • SCD41 (CO2, temperature, humidity)
  • BH1750 (light intensity)
  • APDS-9960 (gesture sensor)
  • and many other sensors – find out more about the μSup connector on our blog
• Dimensions:
  • Length: 46 mm
  • Width: 23 mm
  • Height: 8 mm
• Weight: 6 g

You might also need:

• LED strip connector (board is supplied without it, 2.54 mm pitch):
  • 1× JST-XH 2.5mm PCB Connector, 4-pin (Straight)
  • 1× JST-XH 2.5mm PCB Connector, 4-pin (Right-Angle)
  • 2× KF128-2.54 Screw Terminal Block for PCB, 2-pin
  • or a pin header
• LED Strip Adapters:
  • LaskaKit ESPwled adapter for LED strip JST-SM-3
  • LaskaKit ESPwled IP67 adapter for LED strip
• Pigtail for IPEX version:
  • Pigtail MHF3/IPEX3 - SMA Female, cable 1,15mm, 15cm
• Enclosure:
  • LaskaKit Enclosure for LaskaKit ESPwled or you can 3D print it yourself

Package contents:

• 1× LaskaKit ESPwled (depending on the selected variant)

Note:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustrative purposes only and may sometimes differ from the actual appearance of the item. However, this does not change their basic properties.
• Neither the 3D printed enclosure nor the LED strip connector are included in the package.
