LCTC LCDSxx75DD3 Non-Contact Slim SSR Relay for DIN Rail DC-DC

Product detailed description

LCTC LCDSxx75DD3 is a compact, contactless DC-DC solid-state relay designed for DIN rail mounting. It enables quiet and reliable switching of DC loads without mechanical wear. Thanks to its slim design, it is ideal for switchboards with limited space. The relay is available in several current variants, allowing it to be used in various applications – from automation to power supply and DC motors.

Other versions:

• Slim DC-AC: LCTC LCDSxx48ZD3
• DC-AC: LCTC SSR-1DA
• DC-DC: LCTC SSR-1DD

Specifications:

• Model: LCTC LCDSxx75DD3 (xx = 10A / 25A / 50A / 80A)
• Type: Slim DC-DC SSR (solid-state relay)
• Control voltage: 3–32 V DC
• Switched voltage: 5–220 V DC
• Switched current: 10A / 25A / 50A / 80A (depending on the variant)
• Output: MOSFET
• Input/output isolation: optocoupler
• Status indication: LED indicator
• Mounting: DIN rail (35 mm standard)
• Design: slim housing to save space
• Usage: DC motor control, LED systems, electromagnets, charging circuits and other DC applications
• Cooling: sufficient air circulation recommended

Package contents:

• 1× LCTC LCDSxx75DD3 SSR relay (in the selected current version)

Comment:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
• Sufficient air circulation must be ensured at higher currents.
• DIN rail is not included in the package.
