RobotDyn Arduino Uno MegaPower ATmega328, FTDI FT232RL

Product detailed description

RobotDyn Arduino Uno MegaPower ATmega328, with USB converter FT232RL.

The most popular arduino board on the market. It is an ideal board for beginners but also for advanced players. It offers a good compromise between price and performance. Thanks to the USB port, you can record as much as you want without any reductions or problems! The board also offers a power jack that can be used to power the board from a battery, for example. On the software side, arduino is programmed via an integrated development environment (Arduino IDE), which offers a simple and clear WIRING programming language. This board is suitable for both beginners and advanced students and thanks to its versatility it can be used in almost any project.

Specifications:

Microcontroller	ATmega328P
Krystal	16MHz
Flash	32kB
SRAM	2kB
EEPROM	1kB
USB - Serial Converter	FT232RL
Inputs and Outputs
Digital I/O	14
PWM	6
Analog Inputs	8
DC Current per pin	40mA
Input voltage	6-12V recommended
5V max Current	1000mA
3.3V max Current	1000mA
Weight	22g

More power ;)

Green and Blue LEDs

Delivery components:

• 1pc RobotDyn Arduino Uno MegaPower ATmega328, FTDI FT232RL

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.

Sources:

• Let's start with Arduino
• ATMega328 Datasheet
• FT232 drivers
• FT232RL Datasheet
• Arduino IDE
• Wiring with Processing IDE(reference) Multiplatform development environment (Win/Linux/Mac/...)
